Model
number |
Bolt Diameter |
Hydraulic
Area |
Max Load |
Tool OD |
Nearest
Obstruction |
Stroke |
| in |
metric |
in2 |
mm2 |
kN |
tonf |
lbf |
in |
mm |
in |
mm |
in |
mm |
| TRM21 |
3/4" |
M20 |
2.41 |
1555 |
233 |
23.38 |
52380.48 |
2.87 |
73 |
5.70 |
145 |
0.472 |
12 |
| 7/8" |
M22 |
0.59 |
15 |
| 1" |
M24 |
| 1-1/8" |
M27 |
| TRM22 |
1-1/4" |
M33 |
4.470 |
2884 |
433 |
43.45 |
97342.27 |
4.25 |
108 |
6.88 |
175 |
| 1-3/8" |
M36 |
| 1-1/2" |
M39 |
| TRM23 |
1-5/8" |
M42 |
8.17 |
5271 |
791 |
79.38 |
177823.87 |
5.32 |
136 |
7.87 |
200 |
| 1-3/4" |
M45 |
| 1-7/8" |
M48 |
| 2" |
M52 |
| TRM24 |
2-1/4" |
M56 |
13.08 |
8445 |
1267 |
127.15 |
284832.93 |
6.77 |
172 |
9.055 |
230 |
| 2-1/2" |
M64 |
| TRM25 |
2-3/4" |
M72 |
18.90 |
12197 |
1830 |
183.66 |
411400.36 |
7.87 |
200 |
10.03 |
255 |
| 3" |
M76 |
| TRM26 |
3-1/4" |
M80 |
25.85 |
16682 |
2502 |
251.10 |
562471.97 |
9.25 |
235 |
11.33 |
288 |
| 3-1/2" |
M90 |
| TRM27 |
3-3/4" |
M95 |
27.17 |
17530 |
2629 |
263.84 |
591022.71 |
9.64 |
245 |
12.59 |
320 |
| 4" |
M100 |
| TRM29 |
1-7/8" |
M48 |
10.82 |
6983 |
1047 |
105.07 |
235374.96 |
6.141 |
156 |
9.055 |
230 |
| 2" |
M52 |
| 2-1/4" |
M56 |
